4K Optical Extender HDMI 2.0a (FTHS)

4K HDMI Extender (FTHS)

FTHS is a unique fiber optical transceiver that lets you connect your digital UHD monitor to your PC up to 200 meters (656 ft) away from your host source on HDMI standard without signal degradation. This optical extender transmits video quality up to 4K UHD (3840×2160 or 4096×2160 @ 60 Hz) resolution.

Signal:                         HDMI 2.0a
Video Bandwidth:    18 Gbps
Resolution:                4K UHD (3840×2160 or 4096×2160 @ 60 Hz)
Distance:                    200M (656 ft)
Connector:                 HDMI type A (Female)




This unique fiber optical transceiver lets your PC, digital UHD monitor extend up to 200 meters (656ft) away from the host based on HDMI standard without signal degradation by UHD (3840×2160 or 4096×2160 @60Hz) resolution.


▪ High Speed and long-distance transmission by optical system
▪ Compatible with HDMI standard V2.0a
▪ Supports 50-micron OM3 or OM4 Fiber with an SC Connector
▪ Main-link video signal / DDC data and Hot Plug Detection signal is transmitted by-
1-channel multimode optical fiber
▪ External power supply use(TX, RX)
▪ SCDC(Status and Control Data Channel) compliant
▪ HDCP 2.2 compliant
▪ EMC & Safety: CE, FCC
※ Does not support CEC and HEAC.


Tech Specs:

▪ Input and Output Signal: HDMI 2.0 Standard
▪ Video Bandwidth: 18Gbps
• Dimension : 81.2W x 21.1D x 47.5H (mm)
▪ Optical Connector: SC Connector
▪ Electrical Connector: HDMI type A Connector (Female)
▪ Applied Fiber : OM3 or OM4 Multi-mode glass-fiber.
▪ Maximum Supporting Resolution : UHD(3840×2160 / 4096×2160@60Hz)
▪ Transmission distance: 200 meters (656 ft)
▪ External Power : 5V / 2A (1.35ø DC JACK)
• Power Consumption (transmitter): 3.05W (Typ)
• Power Consumption (receiver): 2.85W (Typ)
▪ Operating Temperature Range : 0°C ~ 50°C
▪ Storage Temperature Range : -20°C ~ 70°C




Ordering Information:

• Transmitter, Receiver
• Power Adapter 2ea
• 1.0M HDMI cable 2ea
• User’s manual
