4K 12G SDI Splitter (OSS-104)


OPHIT’s 4K 12G-SDI splitter lets your single SDI signal connect with up to four SDI outputs.

Connector:                12G-SDI (via BNC female connector) – Input: 1 / Output: 4
SDI Sources:             12G-SDI, 6G-SDI, 3G-SDI, HD, SD
Resolution:               Up to 4k@60Hz


Date Sheet



OSS-104, the 12G-SDI 1×4 splitter allows one 12G/6G/3G/HD/SD source to be distributed to up to four displays.

• Distributes one SDI input to up to four SDI outputs
• Supports SMPTE video rates up to 11.88Gbps, enabling UHD video for 4k@60
• Supports ST-2082-1(12G), ST-2081-1(6G), ST-424(3G), ST-292(HD), and ST-295(SD)
• Automatically detects the input signal and re-clocks it to attenuate jitter
• Status LED for lock indicator


Tech specs:

• Connector (input): 1 x SDI signal via BNC female connector
• Connector (output): 4 x SDI signal via BNC female connector
• USB Connector: 1 x mini USB-B female connector
• DC Power Jack Connector: 1 x Locking type 2.1 pi power connector
• Video Rates: Up to 11.88 Gbps (ST-2082-1)
• Video Resolution: Up to 4K @ 60 Hz
• Module Dimension: 103 x 109 x 25.8 mm (W x D x H)
• Module Weight: 410g
• Enclosure Color: White
• Power: 1 x External Power Supply – DC + 12V


Ordering Information:

• OSS-104
• 1 x Power Adapter
• User’s manual

Ordering Information
• OSS-104
