4k Multi Scaler Viewer (MSV2)


MSV 2 is controlled by buttons on the unit’s front face, or by a web-based PC interface that also offers live preview. Video input options include 2 dedicated HDMI channels, and 2 channels that can be switched to either HDMI or DisplayPort. Multiple video signals can be combined into one destination layout, such as quad screen, 1 large/3 small, or a user customized layout. Channel switching on MSV 2 is fast and seamless. The MSV 2 user interface dashboard will control previews, screen positioning, preset channel options, input/output coordinates, and much more.

Video Input:             HDMI x 2, HDMI / DP x 2 (user selection)
Video Output:          HDMI x 1
Resolution:               Max 4096 x 2160 @ 60 Hz
4 Preset Mode:         Quad / Fullscreen Mode  (1~4), 3 Side, 3Bottom




MSV2 is an advanced video processor for multimedia presentations. It is a video signal processing device that can output 4 input video signals to one video display device and provides 4 screen output modes. 4ch Inputs of MSV2 have 2 HDMI ports and 2 selectable ports (HDMI or DisplayPort), the user can select the input video the DisplayPort 1.2a or HDMI 2.0 Basically, it supports various output resolutions including up / downscale and supports seamless channel change. Features

▪ Full range of input and output format (Up to 4K@60Hz)
▪ 4 preset modes and 5 user modes
▪ HDMI 2.0, DisplayPort 1.2a Compliant
▪ Supports DisplayPort 1, 2, 4 lanes
▪ Supports HDMI 1.4 / 2.0
▪ Compliant with HDMI 2.0, data rate up to 6Gbps
▪ HDCP 1.4 / 2.2 Compliant
▪ User control: Web, OSD, RS232
▪ 1U Rack type


Tech Specs:

• Input and Output Signal: Input – HDMI x 2
– HDMI / DP x 2 (User Selection)
Output – HDMI x 1
• Dimension: 436(W) x 44(D) x 213(H)mm
• Color: black, ivory
• Maximum Supporting Resolution: 4096×2160@60Hz
• External Power: 12V / 5.00A (2.5ø DC JACK)
• Power Consumption: 25.2W (Typ)
• Operating Temperature Range: 0℃ to 40℃
• Storage Temperature Range: -20℃ to 70℃


Ordering Information:

• MSV2
• 1 Power Adapter
• 1 Power Cord
• User’s manual
