4K Optical DisplayPort 1.2 Extender (FTDS)

DP 1.2 Extender

FTDS is a DisplayPort 1.2 optical fiber extender that complies with DisplayPort 1.2 standards and supports real 4K UHD (3840×2160 or 4096×2160 @60 Hz) resolution. Capable of transmitting high-quality 4K resolution up to 200 meters (656 ft) over only a single SC multi-mode fiber without any signal degradation.

Signal:                         DisplayPort 1.2
Video Bandwidth:    21.6 Gbps
Resolution:                4K UHD (3840×2160 or 4096×2160 @ 60 Hz)
Distance:                    200M (656ft)
Connector/Fiber:     DisplayPort 20 Pin (male)




This unique fiber optical transceiver lets your PC, digital HDTV, or Projector extend up to 200 meters (656ft) away from the host based on DisplayPort standard without signal degradation by UHD (3840×2160 or 4096×2160 @60Hz) resolution.


▪ High Speed and long-distance transmission by the optical system
▪ Compatible with DisplayPort standard V1.2
▪ Supports 50-micron OM3 or OM4 Fiber with an SC Connector
▪ Main-link video signal / AUX data and Hot Plug Detection signal are transmitted by 1-channel multimode optical fiber
▪ External power supply use(TX, RX)
▪ Mode switch use(TX, RX)
▪ DPCD(DisplayPort Configuration Data) compliant
▪ DPCP or HDCP compliant
▪ EMC & Safety: CE, FCC


Tech Specs

• Input and Output Signal: DISPLAYPORT 1.2a Standard
• Video Bandwidth: 21.6Gbps
• Dimension : 81.2W x 21.1D x 47.5H (mm)
• Optical Connector: SC Connector
• Electrical Connector: DisplayPort 20 Pin Connector (Female)
• Applied Fiber : OM3 or OM4 Multi-mode glass-fiber.
• Maximum Supporting Resolution : UHD(3840×2160 / 4096×2160@60Hz)
• Transmission distance: 200 meters (656 ft)
• External Power : 5V / 2A (1.35ø DC JACK)
• Power Consumption (transmitter): 1.75W (Typ)
• Power Consumption (receiver): 2.0W (Typ)
• Operating Temperature Range : 0°C ~ 50°C
• Storage Temperature Range : -20°C ~ 70°C



Ordering Information

• Transmitter, Receiver
• Power Adapter 2ea
• 1.8m DisplayPort cable 2ea
• User’s manual
