Overview
DP/Mini-DP AOC
FTAD2 is a detachable DisplayPort AOC (Active Optical Cable).
The FTAD2 consists of a transmitting part and a receiving part, both of which are connected by a hybrid cable (optical cable & electric cable). The FTAD2’s transmitter is connected to the DisplayPort source device, and the receiver is connected to the DisplayPort sink device. The Mini-DisplayPort ports are also able to be used with source and sink devices.
Features
▪ High-speed and long-distance transmission by optical system
▪ Input and Output Signal: DisplayPort 1.2a/1.4
▪ MMF optical fiber + copper hybrid cable structure
▪ DPCD/HDCP compliant
▪ AUX and Hot Plug channels are transmitted by copper line
▪ Maximum transmission distance: 100m
▪ Connector: DisplayPort 20pin (Male) or Mini-DisplayPort Plug
▪ Mini-DisplayPort (Source) to Mini-DisplayPort (Display) connectivity is possible
▪ No external power supply required
Tech Specs
• Connector (transmitter): DisplayPort 20pin (male) or Mini-DisplayPort Plug
• Connector (receiver): DisplayPort 20pin (male) or Mini-DisplayPort Plug
• Applied Fiber: 50/125 ㎛ Multi-mode glass-fiber
• Video Bandwidth : 32.4 Gbps(HBR3)
• Supporting Resolution & Distance
– 7680X4320@60Hz / 100M (328ft)
• Power Consumption (transmitter): 0.122W (Typ)
• Power Consumption (receiver): 0.264W (Typ)
• Module Dimensions
-66.5(W) x 19.8(D) x 11.9(H)mm
• Operating Temperature Range : 0°C ~ 50°C
• Storage Temperature Range : -20°C ~ 70°C
Configuration
Ordering Information
Package
• FTAD2
• User’s manual
Ordering Information
• FTAD2-AXXX : FTAD2 Cable XXX meters (Max. 100m)
